Draw Circle on GoogleMap

Anonymous

22:35

With Google Play services v3.0, now we can draw circle on Google Maps API V2. To use the new feature, you have to update Android SDK Platform-tools.

The code modify from the exercise of Draw Polygon on GoogleMap.

package com.example.androidmapsv2;

import com.google.android.gms.common.ConnectionResult;
import com.google.android.gms.common.GooglePlayServicesUtil;
import com.google.android.gms.maps.GoogleMap;
import com.google.android.gms.maps.GoogleMap.OnMapLongClickListener;
import com.google.android.gms.maps.MapFragment;
import com.google.android.gms.maps.model.CircleOptions;
import com.google.android.gms.maps.model.LatLng;
import android.app.Activity;
import android.app.AlertDialog;
import android.app.FragmentManager;
import android.graphics.Color;
import android.os.Bundle;
import android.view.Menu;
import android.view.MenuItem;
import android.widget.TextView;
import android.widget.Toast;

public class MainActivity extends Activity
 implements OnMapLongClickListener{

 final int RQS_GooglePlayServices = 1;
 private GoogleMap myMap;

 TextView tvLocInfo;

 @Override
 protected void onCreate(Bundle savedInstanceState) {
  super.onCreate(savedInstanceState);
  setContentView(R.layout.activity_main);

  tvLocInfo = (TextView)findViewById(R.id.locinfo);

  FragmentManager myFragmentManager = getFragmentManager();
  MapFragment myMapFragment
   = (MapFragment)myFragmentManager.findFragmentById(R.id.map);
  myMap = myMapFragment.getMap();

  myMap.setMapType(GoogleMap.MAP_TYPE_HYBRID);

  myMap.setOnMapLongClickListener(this);

 }

 @Override
 public boolean onCreateOptionsMenu(Menu menu) {
  // Inflate the menu; this adds items to the action bar if it is present.
  getMenuInflater().inflate(R.menu.activity_main, menu);
  return true;
 }

 @Override
 public boolean onOptionsItemSelected(MenuItem item) {
  switch (item.getItemId()) {
     case R.id.menu_legalnotices:
      String LicenseInfo = GooglePlayServicesUtil.getOpenSourceSoftwareLicenseInfo(
        getApplicationContext());
      AlertDialog.Builder LicenseDialog = new AlertDialog.Builder(MainActivity.this);
      LicenseDialog.setTitle("Legal Notices");
      LicenseDialog.setMessage(LicenseInfo);
      LicenseDialog.show();
         return true;
     }
  return super.onOptionsItemSelected(item);
 }

 @Override
 protected void onResume() {

  super.onResume();

  int resultCode = GooglePlayServicesUtil.isGooglePlayServicesAvailable(getApplicationContext());

  if (resultCode == ConnectionResult.SUCCESS){
   Toast.makeText(getApplicationContext(),
     "isGooglePlayServicesAvailable SUCCESS",
     Toast.LENGTH_LONG).show();
  }else{
   GooglePlayServicesUtil.getErrorDialog(resultCode, this, RQS_GooglePlayServices);
  }

 }

 @Override
 public void onMapLongClick(LatLng point) {
  tvLocInfo.setText("New circle added@" + point.toString());

  CircleOptions circleOptions = new CircleOptions()
  .center(point)   //set center
  .radius(1000)   //set radius in meters
  .fillColor(Color.RED)
  .strokeColor(Color.BLACK)
  .strokeWidth(5);

  myMap.addCircle(circleOptions);
 }

}
